ZLA-25L Semi-automatic Auger filling machine
Descriptive abstract
This type can do dosing and filling work. Due to the special professional design, so it is suitable to the fluidic or low-fluidity materials, like coffee powder, wheat flour, condiment, solid drink, veterinary drugs, dextrose, pharmaceuticals, powder additive, talcum powder, agriculture pesticide, dyestuff, and so on.
Əsas xüsusiyyətləri
Stainless steel structure;Quick disconnecting or split hopper could be washed easily without tools.
Servo motor drive screw.
PLC & touch screen make it be easy of operation.
Çəki Əlaqə və nisbət izi, müxtəlif maddələrin müxtəlif nisbətində dəyişən paketli çəki çatışmazlığından xilas olur.
Save the parameter of different filling weight for different materials. To save 10 sets at most
Replacing the auger parts, it is suitable for material from super thin powder to granule.
Main Technical Data
Hopper | Quick disconnecting hopper 25L |
Qablaşdırma çəkisi | 10 - 1000g |
Qablaşdırma dəqiqliyi | ≤ 100g,≤±2%; 100 – 500g, ≤±1%; ≥500g,≤±0.5% |
Doldurma sürəti | 5 – 20 times per min |
Enerji təchizatı | 3P AC208-415V 50/60Hz |
Ümumi güc | 2.25Kw |
Ümumi Çəki | 350kg |
Overall Dimensions | 1205×1010×2174mm |
